MESON
The Meson is a two way, floor standing loudspeaker with large scale performance. 25 years of research and experience distilled into a compact cabinet with a surprisingly large and three dimensional soundscape.
Features:
Divine proportioned, acoustical elliptic cabinet milled from solid, long fibre, wood and resin stock for rigidity and resonance control.
Over proportioned, forward firing port communicates impulse response into room pressure.
Drivers:
Wide Band: (100hz to 20Khz): Long fibre, paper diaphragm, underhung voice coil, copper shorting sleeve, aluminium phase plug with copper coating, inverted butyl rubber surround, braced, non-resonant, composite frame.
Acoustic Suspension in golden means elliptical chamber.
Bass: (35hz – 100hz) 6.5″ woofer, proprietary cone with natural fibers – coated papyrus reduces resonance, low damping rubber surround, fiberglass voice coil former for minimum damping, cast aluminium frame, extended copper sleeve on pole piece for low inductance and low distortion.
Downward firing, floor coupled, slot loaded, bass reflex achieves 35hz.
Crossover: 100Hz, 2nd Order
(below range of sensitivity)
Technical details
Frequency response: 35Hz – 21,000 Hz
Sensitivity: 90db/watt/meter
Impedance: 8 ohms (stable for tube amplifiers, a perfect partner for 300B or other 8 watt or greater amplifier)
Recommended Power: 8 watts
Max Power: 50 watts
Meson: a subatomic particle made of one quark and one antiquark, bound together by the strong force.
(The strong force is one of the four fundamental forces of nature — the one that binds quarks together inside protons and neutrons, as well as binding neutrons together inside atomic nuclei.
Please email us for price and availability
